EATON HJDB3200 SERIES C MOLDED CASE CIRCUIT BREAKER 3 POLE 200 AMP 600V 65KAIC

EATON HJDB3200 MOLDED CASE CIRCUIT BREAKER 3 POLE 200 AMP 600V 65KAIC SERIES C

3-Pole • 200 Amp • 600 VAC / 250 VDC • Series C • J-Frame

Condition

NEW OPEN BOX

New open-box item. Original factory box included.

Product Details

This listing is for an Eaton Series C HJDB3200 molded case circuit breaker featuring a 3-pole configuration and a 200-amp current rating. Designed for compatible electrical distribution applications, this J-Frame breaker is rated for 600 VAC / 250 VDC.

The breaker features an interchangeable thermal-magnetic trip unit, catalog number J3200T, with magnetic pickup settings. Its listed interrupting capacities vary by system voltage. Please verify the breaker’s ratings, trip unit, terminal requirements, and compatibility with your equipment before purchasing.

Product Information

• Manufacturer: Eaton
• Model / Catalog Number: HJDB3200
• Style Number: 1481D95G14
• Product Series: Series C
• Frame Type: J-Frame (HJDB 65k)
• Product Type: Molded Case Circuit Breaker
• Number of Poles: 3
• Current Rating: 200 Amps
• Voltage Rating: 600 VAC / 250 VDC
• Interrupting Capacity (AIC): 65,000 A at 480 VAC / 100,000 A at 240 VAC / 25,000 A at 600 VAC
• Trip Unit: Interchangeable thermal-magnetic, catalog J3200T
• Terminal Type / Wire Rating: TA250KB, #4–350 AWG Cu/Al (as provided)
• UPC: 782113928845
• Weight: 9.1 lbs
• Approvals: UL Listed, CSA Certified
• Country of Origin: Dominican Republic

Included

• Eaton HJDB3200 molded case circuit breaker
• Original factory box

Only the items listed above and shown in the listing photos are included. Please review all photos carefully to confirm the item's condition and included components.

Please Note

Electrical equipment must be selected and installed by qualified personnel in accordance with applicable codes and manufacturer requirements. Confirm compatibility with your panel, bus configuration, trip unit, voltage, and available fault current before installation.

Product specifications are provided for identification and reference. Please verify all ratings and markings against the actual product before use.
